Product Description
1.Product Overview
118000519 is a high-performance enterprise grade solid-state drive that features a 12Gb/s SAS interface and a 2.5-inch form factor, providing 3.84TB of storage capacity. This hard drive is designed specifically for VMAX series storage systems, compatible with 5052110 storage expansion shelves, and uses PM1633A enterprise grade disk bodies to provide highly reliable storage solutions for critical business operations.
2. Core specification parameters
Project Specification Description
Brand and Model 118000519
Compatible with expansion shelf 5052110
Disk model PM1633A
Interface type SAS-3 (12.0 Gb/s)
Physical specification 2.5 inches
Capacity 3.84 TB
Flash memory type MLC NAND
Read/write performance sequential read: 1800 MB/s
Sequential writing: 1200 MB/s
3. Performance characteristics
High performance:
Sequential read speed: up to 1800 MB/s
Sequential write speed: up to 1200 MB/s
Random read performance: up to 250000 IOPS
Random write performance: up to 60000 IOPS
Average latency:<120 μ s
Enterprise level durability:
Daily full disk write count: 5 DWPD
Total number of bytes written: 35000 TBW
Supports 24/7 uninterrupted operation
Design service life: 5 years
Advanced data protection:
End to end data path protection
Power outage protection (PLP) function
Advanced ECC error correction mechanism
RAID optimization support
4. Technical characteristics
Interface features:
SAS-3 (12.0 Gb/s) interface
Support dual port redundancy
Backward compatible with SAS-2 (6.0 Gb/s)
Support multi-path access
Power consumption management:
Working power consumption: 10-16W
Standby power consumption: 5W
Support energy-saving mode
Dynamic power consumption regulation
Environmental specifications:
Working temperature: 0°C to 55°C
Storage temperature: -40°C to 70°C
Working humidity: 5% to 95% RH
Anti vibration capability: meets enterprise level standards
5. Compatibility information
Support system:
VMAX 100K/200K/400K series
VMAX All Flash Series
PowerMax series (compatibility verification required)
Storage expansion shelf:
Specially optimized design for 5052110 storage expansion shelf
Support hot swappable installation
Plug and Play configuration
Support online expansion
6. Application scenarios
Database application:
Oracle Database
Microsoft SQL Server
IBM DB2
SAP HANA
Virtualization environment:
VMware HANA virtualization platform
Microsoft Hyper-V Environment
Virtual Desktop Infrastructure (VDI)
Enterprise applications:
Large scale transaction processing system
data warehouse
High Performance Computing
Backup and disaster recovery system
7. Management and maintenance
Monitoring function:
S. M.A.R.T. status monitoring
Real time temperature monitoring and warning
Service life monitoring
Performance statistics and reports
Maintenance features:
Support online hot swappable replacement
Firmware online rolling upgrade
Diagnostic tool support
Remote management function
8. Service Support
Technical support: Original factory technical service
Global warranty: providing international warranty services
9. Physical specifications
Size: 100.0 × 69.85 × 14.8 mm
Weight: Approximately 160g
Interface type: SAS (SFF-8639)
Installation method: 2.5-inch hot swappable bracket
Material: Metal shell, enhanced heat dissipation
