EMC Enterprise NVMe Solid State Drive - Model 118000632/005052584 Product Detailed Description
1. Product Overview
The EMC 118000632/005052584 (Model PM1643) is a high-performance enterprise-grade NVMe SSD with a capacity of 1.92TB. Utilizing advanced 3D TLC NAND flash technology, this product is based on PCIe interfaces and NVMe protocols, delivering reliable performance for enterprise workloads. It serves as an ideal choice for building modern storage infrastructure.
II. Detailed Technical Specifications
Parameter Category Detailed Specifications
Basic Information
EMC Part Number 118000632/005052584
Disk Model: PM1643
Flash memory type: 3D TLC NAND
Interface Protocol: NVMe over PCIe 3.0
Physical dimensions: 2.5-inch U.2
Capacity information
Nominal Capacity 1.92TB
Available user capacity ≈1.75TB
Performance parameters
Sequential read speed: 3,200 MB/s
Sequential write speed: 1,800 MB/s
4K Random Read: 600,000 IOPS
4K Random Write 150,000 IOPS
Read/Write Latency: Read <90μs, Write <20μs
Reliability parameters
Durability Rating: 3 DWPD
Service life 10.5 PBW
Mean Time Between Failures: 2,000,000 hours
Warranty Policy: 5-Year Limited Warranty
III. Core Technologies and Features
1. High-performance architecture
PCIe 3.0 x4 interface
NVMe-optimized protocol stack
High-performance flash memory controller
Support for multiple namespaces
2. Enterprise-level reliability
Power Failure Protection Mechanism: Data Integrity Assurance
End-to-end data protection: complete verification mechanism
Advanced Error Correction: LDPC Error Correction Technology
Smart Wear Leveling: Extend Lifespan
3. Smart Management Function
Hot-swap support: Online maintenance capability
Health Status Monitoring: S.M.A.R.T. Attributes
Temperature Management: Dynamic Thermal Regulation
Remote Management: Standard Management Interface
IV. Compatibility Information
Supported Dell EMC Systems:
Unity Series Storage Arrays
PowerEdge series servers
VxRail Hyper-Converged System
Specific model of PowerMax system
Operating System Support:
VMware vSphere 6.7 or later
Windows Server 2016/2019
Red Hat Enterprise Linux 7/8
SUSE Linux Enterprise Server 12/15
V. Recommended Application Scenarios
1. General enterprise workloads
Virtualization Platform Storage
Medium-sized database applications
File Sharing Service
2. Cloud Infrastructure
Virtual Machine Image Storage
Container persistent storage
Development and Testing Environment
3. Commercial Applications
Mail server storage
Web application storage
Collaboration Platform Storage
4. Data Protection
Backup Storage Acceleration Layer
Disaster Recovery Storage
Data Tiered Storage
VI. Summary of Product Advantages
Performance advantage
Balanced read and write performance
Stable low latency
Excellent IOPS performance
Reliability advantage
Enterprise-grade durability design
Comprehensive data protection
long life cycle
Cost advantage
Optimized total cost of ownership
High-Efficiency Design
Low maintenance cost
7. Environmental Specifications
Parameter Specification
Operating temperature: 0°C to 55°C
Storage temperature: -40°C to 70°C
Operating humidity: 8% to 90% non-condensing
Typical power consumption: 8-10W
Maximum power consumption: 15W
Vibration resistance
Compliant with enterprise-level standards
