EMC Enterprise NVMe Solid State Drive - Model 118000835 Product Details
1、 Product Overview
EMC 118000835 (disk body model PM1733) is a high-performance enterprise grade NVMe solid-state drive with a capacity of 3.84TB. The product uses advanced 3D TLC NAND flash technology, based on PCIe 4.0 interface and NVMe protocol, designed specifically for the high demand workloads of modern data centers, achieving excellent balance in performance, capacity, and reliability.
2、 Detailed technical specifications
Detailed specifications of parameter categories
Basic Information
EMC part number 118000835
Disk model PM1733
Flash technology 3D TLC NAND
Interface protocol NVMe 1.4 over PCIe 4.0
Appearance specification 2.5 inches U.2 (15mm thickness)
Capacity information
Nominal capacity 3.84TB
User available capacity ≈ 3.5TB
performance parameters
Sequential read speed 7000 MB/s
Sequential write speed 4200 MB/s
4K random read 1400000 IOPS
4K random write 300000 IOPS
Read/write delay: Read<65 μ s, write<10 μ s
Reliability parameters
Durability level 3 DWPD
Service life 21 PBW
Mean time between failures 2500000 hours
Annual failure rate 0.35%
Warranty Policy 5-year Limited Warranty
3、 Core Technologies and Characteristics
1. High performance architecture design
PCIe 4.0 x4 interface, providing a transfer rate of 16 GT/s
Support multiple namespaces and SRIOV virtualization
Optimized parallel processing architecture
Low power and high-performance controller
2. Enterprise level reliability assurance
Full path power-off protection: enhanced supercapacitor array
End to end data protection: complete data path protection
Advanced LDPC Error Correction: Fourth Generation LDPC Error Correction Technology
Intelligent Health Monitoring: Real time Flash Health Management System
3. Intelligent management function
Hot swappable support: Compliant with NVMe hot swappable standards
Telemetry: Real time performance monitoring and analysis
Intelligent Temperature Control: Multi zone Dynamic Temperature Management
Remote management: NVMe MI 1.2 management interface
4、 Compatibility information
Supported Dell EMC Systems:
PowerMax 2500/8500 Full Flash Array
Unity XT 380F/480F/680F/880F
PowerEdge MX series modular servers
VxRail P-series hyper fusion system
Software environment support:
VMware HANA 7.0 U3 and above
Windows Server 2022
Red Hat Enterprise Linux 8.5 and above
SUSE Linux Enterprise Server 15 SP3
5、 Recommended application scenarios
1. Key business of the enterprise
Large scale database system (Oracle Exadata)
SAP HANA In Memory Computing Platform
Enterprise Resource Planning System
2. Virtualization and Cloud Computing
Enterprise level virtualization platform
Hyper converged infrastructure
Hybrid cloud storage solution
3. Data analysis and AI
Real time data analysis platform
Artificial Intelligence/Machine Learning Training
Big data processing cluster
4. High performance computing
Scientific research computation
Financial risk modeling
Media content creation
6、 Summary of Product Advantages
performance advantage
PCIe 4.0 Ultimate Performance Performance
Ultra low latency response
Excellent random read and write performance
Capacity advantage
High storage density design
Optimized spatial efficiency
Good scalability
Reliability advantage
Enterprise level durability design
A comprehensive data protection mechanism
Long life cycle guarantee
7、 Environmental specifications
Parameter specifications
Working temperature: 0 ° C to 55 ° C
Storage temperature -40 ° C to 85 ° C
Working humidity 5% to 95% non condensing
Working altitude 3050 meters
Typical power consumption 12-14W
Maximum power consumption 25W
Impact resistance 1000G (0.5ms)
