EMC Enterprise NVMe Solid State Drive - Model 118000839 Product Detailed Description
1. Product Overview
The EMC 118000839 (Part Number: 005053704) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. This product utilizes the latest 3D TLC NAND flash technology, based on the PCIe 4.0 interface and NVMe protocol, specifically designed for demanding workloads in modern data centers, achieving an exceptional balance of performance, reliability, and energy efficiency.
II. Detailed Technical Specifications
Parameter Category Detailed Specifications
Basic Information
EMC Part Number 118000839
Replacement Part Number 005053704
Flash Memory Technology: 3D TLC NAND
Interface Protocol: NVMe 1.4 over PCIe 4.0
Form factor: 2.5-inch U.2
Capacity information
Nominal Capacity: 1.92TB
User available capacity ≈1.75TB
Performance Parameters
Sequential read speed: 6,900 MB/s
Sequential write speed: 3,600 MB/s
4K Random Read 980,000 IOPS
4K Random Write 230,000 IOPS
Read/Write Latency: Read <68μs, Write <11μs
Reliability parameters
Durability Level 3 DWPD
Service life: 10.5 PBW
Mean Time Between Failures: 2,500,000 hours
Annual failure rate: 0.35%
Warranty Policy: 5-Year Limited Warranty
3. Core Technologies and Features
1. High-performance architecture
PCIe 4.0 x4 interface, offering a data transfer rate of 16 GT/s
Supports multiple namespaces and SR-IOV
Optimized parallel processing architecture
Low-power high-performance controller
2. Enterprise-level reliability
Full Path Power Failure Protection: Enhanced Super Capacitor
End-to-end data protection: comprehensive data integrity verification
Advanced LDPC Error Correction: Fourth-Generation LDPC Error Correction
Smart Health Monitoring: Real-time Flash Memory Health Management
3. Smart Management Function
Hot-swap support: Compliant with NVMe hot-swap standards
Telemetry: Real-time Performance Monitoring
Smart Temperature Regulation: Multi-Zone Temperature Sensors
Remote Management: NVMe-MI 1.1 Management Interface
IV. Compatibility Information
Supported Dell EMC Systems:
PowerMax 2500/8500 All-Flash Array
Unity XT 380F/480F/680F/880F
PowerEdge MX series servers
VxRail P Series/V Series
Software Environment Support:
VMware vSphere 7.0 U3 and above
Windows Server 2022
Red Hat Enterprise Linux 8.5 or later
SUSE Linux Enterprise Server 15 SP3
V. Recommended Application Scenarios
1. Key Business of Enterprises
Medium-sized database system
Virtualization platform storage
Enterprise application server
2. Cloud computing environment
Private cloud storage infrastructure
Hybrid cloud storage solution
Cloud-native application storage
3. Data Analysis
Real-time data processing
Business Intelligence Analysis
Machine learning inference workloads
4. Virtualization Deployment
Virtual Desktop Infrastructure (VDI)
Server virtualization
Container platform storage
