EMC Enterprise NVMe Solid State Drive - Model 118000838 Product Detailed Description
1. Product Overview
The EMC 118000838 (model number PM1733) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. This product utilizes advanced 3D TLC NAND flash technology, featuring a PCIe 4.0 interface and NVMe protocol, delivering exceptional performance and reliability for enterprise workloads. It serves as an ideal storage solution for building modern data centers.
II. Detailed Technical Specifications
Parameter Category Detail Specifications
Basic Information
EMC Part Number 118000838
Disk Model: PM1733
Flash memory type: 3D TLC NAND
Interface Protocol: NVMe over PCIe 4.0
Form factor: 2.5-inch U.2
Capacity information
Nominal Capacity: 1.92TB
Available user capacity ≈1.75TB
Performance parameters
Sequential read speed: 6,500 MB/s
Sequential write speed: 3,200 MB/s
4K Random Read 900,000 IOPS
4K Random Write 200,000 IOPS
Read and Write Latency: Read <75μs, Write <15μs
Reliability parameters
Durability Rating: 5 DWPD
Service life: 17.5 PBW
Mean Time Between Failures: 2,500,000 hours
Annual failure rate: 0.44%
Warranty Policy: 5-Year Limited Warranty
III. Core Technologies and Features
1. High-performance architecture design
PCIe 4.0 x4 interface, delivering high bandwidth
Supports NVMe 1.4 standard features
Optimized Flash Controller
Low-latency architecture design
2. Enterprise-level Reliability
Power Failure Protection Mechanism: Super Capacitor Data Protection
End-to-end data protection: comprehensive data integrity verification
Advanced Error Correction: LDPC Error Correction Technology
Intelligent Wear Leveling: Dynamic Block Management
3. Smart Management Function
Hot-swap support: Online maintenance capability
Health Status Monitoring: Enhanced S.M.A.R.T
Temperature Management: Dynamic Temperature Control Adjustment
Remote Management: NVMe-MI Management Interface
IV. Compatibility Information
Supported Dell EMC Systems:
PowerMax 2500/8500 Series
Unity XT 380F/480F/680F/880F
PowerEdge MX Series Servers
VxRail P Series/V Series
Operating System Support:
VMware vSphere 7.0 or later
Windows Server 2019/2022
Red Hat Enterprise Linux 8/9
SUSE Linux Enterprise Server 15
V. Recommended Application Scenarios
1. Key Enterprise Applications
Medium-sized database system
Virtualization platform storage
Enterprise application server
2. Cloud Computing Environment
Private cloud storage infrastructure
Hybrid Cloud Storage Solution
Cloud-native application storage
3. Data Analysis
Real-time data processing
Business Intelligence Analytics
Machine learning workloads
4. Virtualization Deployment
Virtual Desktop Infrastructure (VDI)
Server virtualization
Container platform storage
