EMC Enterprise NVMe Solid State Drive - Model 118000748-01 Product Details
1、 Product Overview
EMC 118000748-01 is a product that uses Intel technology ® The latest 3D NAND flash technology for ultra large capacity enterprise NVMe solid-state drives, with a capacity of up to 7.68TB. This product is based on PCIe 4.0 interface and NVMe protocol, designed specifically for the extreme performance requirements of modern data centers, setting a new industry benchmark in storage density, performance, and reliability.
2、 Detailed technical specifications
Detailed specifications of parameter categories
Basic Information
EMC part number 118000748-01
Flash technology from Intel ® 144 layer 3D TLC NAND
Interface protocol NVMe 1.4 over PCIe 4.0
Appearance specification 2.5 inches U.2 (15mm thickness)
Capacity information
Nominal capacity 7.68TB
User available capacity ≈ 7.0TB
performance parameters
Sequential read speed 7200 MB/s
Sequential write speed 4500 MB/s
4K random read 1600000 IOPS
4K random write 350000 IOPS
Read/write delay: Read<65 μ s, write<8 μ s
Reliability parameters
Durability level 3 DWPD
Service life 84 PBW
Mean time between failures 2500000 hours
Unrepairable error rate<1e-17
Warranty Policy 5-year Limited Warranty
3、 Core Technologies and Characteristics
1. Intel ® Innovative Flash Memory Technology
Adopting 144 layer 3D TLC NAND
Innovative floating gate technology
High density storage unit design
Optimized charge retention capability
2. Enterprise level reliability assurance
Full path power-off protection: enhanced supercapacitor array
End to end data protection: complete data path protection
Advanced LDPC Error Correction: Fourth Generation LDPC Error Correction
Intelligent Health Management: Real time Health Status Monitoring
3. Intelligent management function
Hot swappable support: Compliant with NVMe hot swappable standards
Health status monitoring: Telemetry 2.0 telemetry
Intelligent temperature control: Multi zone temperature sensor
Remote management: NVMe MI 1.2 management interface
4、 Compatibility information
Supported Dell EMC Systems:
PowerMax 2500/8500 Full Flash Array
PowerEdge MX series modular servers
Unity XT 680F/880F hybrid storage
VxRail P-series hyper fusion system
Software environment support:
VMware HANA 7.0 U3 and above
Windows Server 2022
Red Hat Enterprise Linux 8.5 and above
SUSE Linux Enterprise Server 15 SP3
5、 Recommended application scenarios
1. Ultra large scale data center
Hyper converged infrastructure
Software defined storage platform
Cloud service provider infrastructure
2. Key business of the enterprise
Ultra large database system
Enterprise level data warehouse
Key business application storage
3. Artificial Intelligence and Big Data
AI training platform storage
Machine learning workloads
Big data analysis platform
4. High performance computing
Scientific research computation
Financial modeling analysis
4K/8K video processing
