EMC Enterprise NVMe Solid State Drive - Model 118000588-04 Product Details
1、 Product Overview
EMC 118000588-04 (part number: 005053504) is a high-performance enterprise grade NVMe solid state drive that utilizes Western Digital's advanced flash technology, with a capacity of 3.84TB. The product is based on PCIe 4.0 interface and NVMe protocol, designed specifically for high demand workloads in modern data centers, achieving outstanding performance in terms of performance, reliability, and energy efficiency.
2、 Detailed technical specifications
Detailed specifications of parameter categories
Basic Information
EMC part number 118000588-04
Alternative part number 005053504
Flash Memory Technology Western Digital 3D TLC NAND
Interface protocol NVMe 1.4 over PCIe 4.0
Appearance specification 2.5 inches U.2
Capacity information
Nominal capacity 3.84TB
User available capacity ≈ 3.5TB
performance parameters
Sequential read speed 6800 MB/s
Sequential write speed 4000 MB/s
4K random read 1100000 IOPS
4K random write 280000 IOPS
Read/write delay: Read<75 μ s, write<12 μ s
Reliability parameters
Durability level 5 DWPD
Service life 35 PBW
Mean time between failures 2500000 hours
Annual failure rate 0.44%
Warranty Policy 5-year Limited Warranty
3、 Core Technologies and Characteristics
1. Western Digital Flash Memory Innovation
Adopting BiCS5 3D TLC NAND technology
112 layer stacked architecture
Innovative charge capture storage technology
High density storage unit design
2. Enterprise level reliability
Complete power-off protection: onboard supercapacitor
End to end data protection: full path data integrity verification
Advanced Error Correction Technology: LDPC Error Correction
Intelligent Wear Balance: Dynamic Wear Balance Algorithm
3. Intelligent management function
Hot swappable support: Compliant with NVMe hot swappable standards
Health status monitoring: real-time monitoring and early warning
Temperature management: Multi zone temperature monitoring
Remote management: NVMe MI management interface
4、 Compatibility information
Supported Dell EMC Systems:
PowerMax 2500/8500 series
Unity XT 380F/480F/680F/880F
PowerEdge MX series servers
VxRail P Series/V Series
Operating system support:
VMware HANA 7.0 and above
Windows Server 2019/2022
Red Hat Enterprise Linux 8/9
SUSE Linux Enterprise Server 15
5、 Recommended application scenarios
1. Key business of the enterprise
Large scale database systems (Oracle, SQL Server)
SAP HANA In Memory Computing Platform
Enterprise Resource Planning System
2. Virtualization environment
Large scale virtualization deployment
Virtual Desktop Infrastructure (VDI)
Containerized platform storage
3. Data analysis and AI
Real time data processing
Business Intelligence Analysis
Machine learning workloads
4. Cloud service infrastructure
Private cloud storage platform
Hybrid cloud storage solution
Cloud native application storage
