EMC Enterprise NVMe Solid State Drive - Model 118000043-01 Product Detailed Description
1. Product Overview
The EMC 118000043-01 (Part Number: 005051102) is a high-performance enterprise-grade NVMe solid-state drive with a capacity of 1.92TB. Utilizing advanced 3D TLC NAND flash technology, this product is based on the PCIe interface and NVMe protocol, delivering exceptional performance and reliability for enterprise workloads, making it suitable for various data center application scenarios.
II. Detailed Technical Specifications
Parameter Category Detailed Specifications
Basic Information
EMC Part Number 118000043-01
Replacement Part Number 005051102
Flash memory type: 3D TLC NAND
Interface Protocol: NVMe over PCIe
Physical dimensions: 2.5-inch U.2
Capacity information
Nominal Capacity 1.92TB
Available user capacity ≈1.75TB
Performance parameters
Sequential read speed: 3,200 MB/s
Sequential write speed: 1,800 MB/s
4K Random Read: 600,000 IOPS
4K Random Write 150,000 IOPS
Read and Write Latency
Read <85μs, Write <15μs
Reliability parameters
Durability Level 3 DWPD
Service life 10.5 PBW
Mean Time Between Failures: 2,000,000 hours
Warranty Policy: 5-Year Limited Warranty
III. Core Technologies and Features
1. High-performance architecture
PCIe 3.0 x4 interface
NVMe Optimized Protocol Stack
High-performance flash memory controller
Support for multiple namespaces
2. Enterprise-level Reliability
Power Failure Protection Mechanism: Data Integrity Assurance
End-to-end Data Protection: Comprehensive Verification Mechanism
Advanced Error Correction: LDPC Error Correction Technology
Smart Wear Leveling: Extend Service Life
3. Smart Management Function
Hot-swapping support: Online maintenance capability
Health Status Monitoring: S.M.A.R.T. Attributes
Temperature Management: Dynamic Temperature Control Adjustment
Remote Management: Standard Management Interface
4、 Compatibility information
Supported Dell EMC Systems:
Unity series storage array
PowerEdge series servers
VxRail hyper fusion system
PowerMax All Flash Array
Operating system support:
VMware HANA 6.7 and above
Windows Server 2016/2019
Red Hat Enterprise Linux 7/8
SUSE Linux Enterprise Server 12/15
5、 Recommended application scenarios
1. General enterprise workloads
Virtualization platform storage
Medium sized database applications
File sharing service
2. Cloud infrastructure
Virtual machine image storage
Container persistent storage
Development and testing environment
3. Commercial applications
Email server storage
Web application storage
Collaborative platform storage
