Product Description

1.Product Overview

Original Enterprise NVMe SSD | 1.92TB PCIe High Speed Solid State Drive with Full Height Active Cooling Bracket (Model: 5563629-A) - Preferred for Speedy System Disk and Cache Acceleration

2.Product Core Highlights

High speed read and write, performance leap: Adopting NVMe over PCIe interface protocol, it provides far faster read and write speeds than traditional SATA/SAS interfaces (sequential read can reach thousands of MB/s), significantly improving system response speed and data throughput efficiency, completely bidding farewell to I/O bottlenecks.

Original heat dissipation, stable and reliable: Equipped with a dedicated full height active heat dissipation bracket (integrated heat dissipation fins and cooling fan), it efficiently controls the operating temperature of enterprise grade NVMe hard drives, ensuring that they do not throttle due to overheating during long-term high-speed operation, and guaranteeing continuous and stable high-performance output.

Enterprise grade quality, durable: derived from the PowerEdge series servers, designed for 7x24 uninterrupted operation, with extremely high TBW (lifetime write) and MTBF (mean time between failures), providing a solid and reliable data storage foundation for critical business applications.

Golden Capacity, Specialized in Use: 1.92TB capacity is the "golden size" for server applications, perfectly matching scenarios that require a balance between speed and capacity, such as operating systems, database caching, virtual machine mirroring, and high-frequency applications. It is a highly cost-effective performance acceleration solution.

Plug and play, seamless integration: The original design of the rack and disk integration (model 5563629-A includes the disk body and bracket) does not require any adapters or compatibility debugging. It can be directly installed into compatible Dell servers for recognition and use, greatly saving deployment time and labor costs.

3.Detailed specification parameters

Parameter Item Parameter Value&Description

Product model 5563629-A (this model represents the complete component including the bracket)

Storage capacity 1920 GB (i.e. 1.92TB, actual capacity after formatting is approximately 1.75TB)

Interface protocol NVMe over PCIe 3.0 x4 (mainstream enterprise standard)

Read and write performance: High speed read and write (specific values need to be determined according to the disk model, with typical values read in sequence exceeding 3000 MB/s)

Appearance specification 2.5 inches (U.2 form)

Includes original full height active cooling bracket (including fan), NVMe drive body, and dedicated baffle

High durability DWPD/TBW (enterprise level standard, ensuring long-term durability)

Mainly suitable for PowerEdge R740/R740xd, R750/R750xa, R730xd (with NVMe backplane required), etc

4.Accurate applicable scenarios and models

Target servers: PowerEdge R740/R740xd, R750/R750xa, FX2/FX4 and other models that support NVMe hard drives. ( Attention: Please make sure to confirm that your server chassis supports "full height" hard drive slots)

Core application scenarios:

High speed system boot disk: As a server operating system disk, it can boot up quickly and load system services quickly.

Database cache acceleration: Provides a caching layer for databases such as Oracle, SQL Server, MySQL, etc., to accelerate queries and processing.

Virtualization platform storage: used to store virtual machine images or as cache disks for vSphere/Hyper-V, improving virtual machine performance.

High performance application storage: used to store applications, log files, or temporary data that require fast reading and writing.

Software defined storage cache: used as a cache tier in environments such as VSAN or Ceph.

5.Purchase Notice (Important Notice)

Health Protection: Each hard drive undergoes strict testing with professional tools before shipment to ensure that SMART information is healthy and alarm free, with short power on time and low write volume. Clear test screenshots are provided for verification.

Compatibility confirmation: It is essential to confirm! Your server model supports NVMe hard drives and the hard drive space is of the "full height" specification. This hard drive with a heat sink cannot be installed in the "half height" or "passive heat sink" slot.

Appearance description: As a server disassembly component, the heat dissipation bracket and disk body may have slight usage marks or scratches, which is a normal phenomenon and does not affect any performance or functionality.

6.Why choose this hard drive?

Original quality, worry free and reliable: avoids compatibility, stability, and heat dissipation risks of third-party NVMe hard drives and heat dissipation brackets.

Ultimate cost-effectiveness: Obtain enterprise grade high-performance storage components that have been rigorously certified by Dell at a highly competitive price.

Ready to use: No additional procurement or assembly required, ready to install and use, greatly simplifying the procurement and operation process.

Professional Choice: This is a professional solution designed for server and data center environments, which is not comparable to consumer grade products in terms of reliability and performance.
