HPE Enterprise NVMe Solid State Drive -874430-002 (PM1633A) Product Introduction

Overview

HPE 874430-002 (disk model PM1633A) is an enterprise grade NVMe solid state drive precisely positioned for reading intensive workloads. This model offers a capacity of 1.92TB and uses a standard 2.5-inch U.2 (SFF-8639) interface and NVMe protocol. It is a model in HPE's product line known for its ultimate cost-effectiveness, designed to provide the high-speed advantage of NVMe for read based enterprise applications while effectively controlling total cost of ownership (TCO), making it an ideal choice for transitioning from SATA/SAS to NVMe.

Core specifications and features

Project specification description

Product model HPE 874430-002

Disk model PM1633A

Capacity 1.92 TB

Interface NVMe 1.2

Appearance specification 2.5 inches, U.2 (SFF-8639)

NAND Type 3D TLC NAND Durability/Durability up to 1.0 DWPD (daily full disk write count within 5-year warranty) or~3.5 PBW (lifetime write count)

Highest performance sequential read speed:~3200 MB/s

Highest sequential write speed:~1100 MB/s

Random read IOPS: up to 500000 (4K)

Random write IOPS: up to 30000 (4K)

Average active power consumption:~8W

Idle power consumption:~4W

Reliability index MTBF: 2500000 hours

UBER:<1 error in every 10 ^ 17 bits read

Main features: Read intensive design: Performance features are highly biased towards read optimization, providing extremely high read throughput and bandwidth, and write performance meets basic requirements.

Cost effectiveness king: It has extremely high cost-effectiveness in the HPE NVMe product line and is the most cost-effective solution for deploying large-scale read scenarios.

Basic enterprise level functionality: equipped with basic data path protection and ECC error correction. Note: As an entry-level enterprise drive, it is typically not equipped with advanced onboard power outage protection (PLP) capacitor arrays, and its data security relies more on the overall design of HPE server platforms.

HPE Genuine Guarantee: As an original component of HPE, it provides out of the box compatibility and reliability for server platforms such as HPE ProLiant and Synergy, and supports monitoring and management through iLO.

Low power consumption: Excellent energy efficiency, helping to reduce the operating costs and carbon emissions of data centers.

Applicable scenarios and applications

This hard drive is an ideal choice for pure read intensive applications, with typical scenarios including:

Content Delivery Network (CDN) and Streaming Media: Store and accelerate the transmission of static content such as videos, audio, software update packages, etc.

Web servers and caching proxies: Quickly load web pages, images, and scripts, significantly improving website responsiveness.

Database read-only replica or report repository: Create dedicated instances for querying and generating reports for large databases such as SQL Server and Oracle, greatly reducing the pressure on the main repository.

Virtualization host boot volume: serves as the boot driver for VMware iPadOS or Microsoft Hyper-V, enabling fast boot and efficient management.

Enterprise VDI boot image storage: In virtual desktop architecture, quickly read and distribute the same operating system image to a large number of users.

Fast access layer for archived data: providing access speeds several orders of magnitude faster than traditional hard drives (HDDs) for infrequently modified "warm data".

Summary of Advantages

Unparalleled cost-effectiveness: With a cost close to high-end SATA SSDs, it provides NVMe level ultimate read performance and a very high return on investment (ROI).

Excellent read performance: With a sequential read speed of up to 3.2 GB/s and 500000 random read IOPS, it can completely eliminate read bottlenecks.

Low power consumption and green energy saving: Lower operating power consumption helps build more environmentally friendly and economical data centers.

Seamless HPE Integration: As an original HPE accessory, it can be seamlessly integrated into the HPE server ecosystem, ensuring drive free compatibility and monitoring and management through iLO.

Sufficient durability: The durability of DWPD is completely sufficient for its target workload (read intensive), ensuring reliable operation during the warranty period.

Important precautions and summary
