HPE 876596-001 240GB NVMe SSD Enterprise Solid State Drive Product Introduction

Product Overview

           HPE 876596-001 is a high-performance enterprise grade NVMe solid state drive that uses HP's own packaged drive body, optimized for the HPE ProLiant Gen10 server platform. This hard drive is positioned for read intensive application scenarios, providing excellent random read performance and stable low latency performance for enterprise users. It is suitable for use as a system boot disk or cache acceleration disk.

1. Core features and specifications

Capacity specification: 240GB

(Adopting enterprise level reserved space design to ensure long-term performance consistency)

Interface protocol: NVMe 1.3 over PCIe 3.1 x4

Appearance specification: 2.5 inches U.2 (SFF-8639)

Performance performance:

Continuous reading speed: up to 3200 MB/s

Continuous write speed: up to 1100 MB/s

Random read IOPS: up to 300000 (4K)

Random write IOPS: up to 40000 (4K)

Durability index:

DWPD: 0.8 (5-year warranty period)

TBW：350TB

MTBF: 2 million hours

Flash Memory Type: 3D TLC NAND

(Using enterprise grade granules to ensure data reliability)

2. Advanced features

Intelligent power management:

Supports multiple power consumption states and can dynamically adjust power consumption according to workload

End to end data protection:

Adopting advanced ECC verification and power-off protection mechanism

Thermal management function:

Built in temperature sensor, supporting intelligent temperature control adjustment

Security features:

Support secure erasure function, in compliance with enterprise data security standards 3. Applicable scenarios

Server system boot:

Provide fast boot support for HPE ProLiant servers

Read intensive applications:

Suitable as a database query cache or virtualization platform storage

Edge computing scenario:

Provide high-performance storage solutions in space constrained environments

Cloud infrastructure:

Virtual machine image storage suitable for cloud platforms

4. Compatibility information

Support platform:

HPE ProLiant DL360 Gen10

HPE ProLiant DL380 Gen10

HPE ProLiant ML350 Gen10

System requirements:

UEFI 2.3.1 or higher version is required

Supports NVMe 1.3 and above protocols

Management tools:

Can be monitored and managed through HPE iLO 5

Support HPE SSM intelligent storage management
