NETAPP Enterprise NVMe Solid State Drive - Model 108-00546 (X371A-R6) Product Details
1、 Product Overview
NETAPP 108-00546 (product model X371A-R6, disk body model PM1635A) is a high-performance enterprise level NVMe solid-state drive with a capacity of 960GB. The product uses advanced flash technology and NVMe protocol to achieve an optimized balance between performance, capacity, and reliability, suitable for various enterprise level application scenarios, and is an ideal choice for mid-range storage needs.
2、 Detailed technical specifications
Parameter Category Detailed Specification Remarks
Basic Information
Manufacturer Model X371A-R6
NETAPP part number 108-00546 unique identification code
Disk model PM1635A
NVMe over PCIe interface protocol supports NVMe 1.3 standard
Appearance specification 2.5 inches U.2 (SFF-8639) enterprise standard appearance
Capacity information
Nominal capacity 960GB original capacity
Available capacity ≈ 880GB considering RAID and system overhead
performance parameters
Sequential read speed up to 3000 MB/s, sustained performance
Sequential write speed up to 1000 MB/s, sustained performance
4K random read up to 400000 IOPS, queue depth 256
4K random write up to 60000 IOPS queue depth 256
Read/write latency reading<95 μ s, write<22 μ s typical value
Reliability parameters
Durability level 3 DWPD daily full disk write count
Service life 5.2 PBW lifetime write capacity
Mean time between failures 2000000 hours
The warranty policy is 5 years or the durability index is reached first
3、 Core Technologies and Characteristics
1. Performance optimization design
Adopting PCIe 3.0 x4 interface, providing high bandwidth
Optimized flash controller architecture
Support multi namespace management
dynamic power management
2. Enterprise level reliability
Power outage protection design: integrated data protection
End to end data protection: complete data verification mechanism
Advanced Error Correction Code: Powerful Error Correction Capability
Wear Balance Algorithm: Intelligent Flash Memory Management
3. Intelligent management features
Hot swappable support: online maintenance capability
S. M.A.R.T. monitoring: real-time health status report
Temperature monitoring: dynamic temperature control adjustment
Firmware online upgrade: no need for downtime maintenance
4、 Compatibility information
Supported NetApp systems:
AFF A series full flash array: A220, A250, etc
FAS series hybrid storage system
Supports ONTAP 9.4 and higher operating systems
Physical compatibility:
Standard 2.5-inch disc position
DS224C and other disk racks
Support hot swappable installation
5、 Recommended application scenarios
1. General Enterprise Applications
Virtualization platforms (VMware, Hyper-V)
Medium sized database applications
file share service
2. Commercial applications
Email server storage
Web application storage
Collaborative platform storage
3. Development and testing environment
Development test platform
Quality assurance environment
Pre production environment
