NETAPP Enterprise NVMe Solid State Drive - Model 108-00856 (X4010A-PM1723B) Product Details
1、 Product Overview
NETAPP 108-00856 (product model X4010A, disk body model PM1723B) is a high-performance enterprise level NVMe solid-state drive with a capacity of 1.92TB. The product uses advanced 3D TLC NAND flash technology and NVMe protocol, optimized for read intensive workloads, achieving a perfect balance between performance, durability, and cost-effectiveness, suitable for various enterprise level application scenarios.
2、 Detailed technical specifications
Parameter Category Detailed Specification Remarks
Basic Information
Manufacturer model X4010A
NETAPP part number 108-00856 unique identification code
Disk model PM1723B
NVMe over PCIe interface protocol supports the latest standards
Appearance specification 2.5 inches U.2 (SFF-8639) industry standard
Capacity information
Nominal capacity 1.92TB original capacity
Available capacity ≈ 1.75TB considering RAID and system overhead
performance parameters
Sequential read speed up to 3200 MB/s, sustained performance
Sequential write speed up to 1200 MB/s, sustained performance
4K random read up to 500000 IOPS queue depth 256
4K random write up to 80000 IOPS queue depth 256
Read/write latency reading<90 s, write<20 typical value
Reliability parameters
Durability level 3 DWPD daily full disk write count
Service life 10.5 PBW lifetime write capacity
Mean time between failures 2000000 hours
The warranty policy is 5 years or the durability index is reached first
3、 Core Technologies and Characteristics
1. High performance architecture design
Adopting PCIe 3.0/4.0 x4 interface, providing high bandwidth data transmission
Support multi queue access and optimize concurrent processing capabilities
Intelligent pre reading algorithm improves sequential reading performance
Low power controller design, balancing performance and energy efficiency
2. Enterprise level reliability assurance
Power outage protection mechanism: integrated supercapacitor to ensure data security in case of sudden power outage
End to end data protection: complete data verification from host to flash memory
Advanced ECC Error Correction: Powerful Error Detection and Correction Capability
Wear leveling algorithm: extending the lifespan of flash memory
3. Intelligent management function
Hot swappable support: supports online replacement to ensure business continuity
S. M.A.R.T. Monitoring: Real time monitoring of hard drive health status
Temperature management: dynamic temperature control adjustment to prevent overheating
Firmware online upgrade: firmware can be updated without shutting down
4、 Compatibility information
Supported NetApp systems:
AFF A series full flash array: A220, A250, A400, etc
FAS series hybrid storage system
Supports ONTAP 9.5 and higher operating systems
Physical compatibility:
Standard 2.5-inch disc position
DS224C, DS460C and other disk racks
Support hot swappable installation
5、 Recommended application scenarios
1. Virtualization environment
VMware HANA virtualization platform
Microsoft Hyper-V Environment
VDI (Virtual Desktop Infrastructure)
2. Enterprise applications
Database read replica (Oracle, SQL Server)
File Sharing Server
Email server storage
3. Cloud and hosting services
Virtual machine image storage
Container persistent storage
Backup and archive storage
4. Read intensive workloads
Content Delivery Network (CDN)
Streaming media services
Big data analysis and query
