NetApp Enterprise NVMe Solid State Drive -108-00883 (X4019A, PM1723B) Product Introduction
Overview
NetApp 108-00883 (part number X4019A, disk body model PM1723B) is a high-capacity high-performance NVMe solid-state drive launched by NetApp. This model offers a capacity of 15.36TB, uses a 2.5-inch U.2 interface, and is based on PCIe 4.0 technology. It is specifically designed for NetApp AFF all flash arrays, providing excellent performance and reliability for enterprise level massive data storage.
Core specifications and features
Project Specification Description
NetApp model 108-00883
Part number X4019A
Disk model PM1723B
Capacity: 15.36TB
Interface protocol NVMe 2.0, PCIe 4.0 x4
Appearance specification 2.5 inches U.2 (SFF-8639)
NAND type 96 layer 3D TLC NAND
Durability/Durability 3 DWPD (daily full disk write count during 5-year warranty period)
Total 84.0 PBW (lifetime write)
Performance sequential reading: up to 6500 MB/s
Sequential writing: up to 3800 MB/s
Random read: 1200000 IOPS (4K)
Random Write: 250000 IOPS (4K)
Delay reading delay 95
Write latency 20
Power consumption activity power consumption 22W
Idle power consumption 6W
Reliability index MTBF 2.5 million hours
UBER 1e
Technical Features
1. Ultra large capacity design
Adopting high-density 3D TLC NAND technology
Support intelligent capacity management
Optimized space utilization
2. Performance characteristics
PCIe 4.0 interface provides high-performance bandwidth
Support multi queue deep operations
Adaptive read-write optimization
3. Reliability characteristics
Enhanced power protection circuit
End to end data integrity protection
Intelligent bad block management
4. Management function
Support NVMe management interface
Real time health status monitoring
Predictive Failure Analysis
Remote diagnostic support
system compatibility
Support platform:
AFF A Series Full Flash Array
AFF C Series Full Flash Array
FAS9500 series hybrid array
System requirements:
ONTAP 9.11.1 or higher version
Recommended ONTAP 9.12.1+
Management tools:
NetApp System Manager
Active IQ Unified Manager
ONTAPI Command Line Interface
Applicable scenarios
1. Big data storage
Massive data warehouse
Data analysis platform
Business Intelligence System
2. Media and Entertainment
4K/8K video editing
Media Asset Management System
Content Distribution Network
3. Virtualization environment
Large scale VDI deployment
Cloud infrastructure
Container storage
4. Backup and Archive
Enterprise level backup system
Long term data archiving
Compliant storage
