NetApp Enterprise NVMe Solid State Drive -108-00687 (X319A-R6, PM1643) Product Introduction
Overview
NetApp 108-00687 (part number X319A-R6, disk body model PM1643) is a high-performance hybrid NVMe solid state drive designed by NetApp specifically for its all flash storage systems. This model offers a capacity of 7.68TB and uses a standard 2.5-inch U.2 interface. Based on the mature PM1643 platform, it provides excellent read-write performance and reliability for NetApp AFF series storage arrays, making it suitable for demanding mixed workload environments.
Core specifications and features
Project Specification Description
NetApp model 108-00687
Part number X319A-R6
Disk model PM1643
Capacity 7.68TB
Interface Protocol NVMe 1.3
Appearance specification 2.5 inches U.2 (SFF-8639)
NAND type 64 layer 3D TLC NAND
Durability/Durability 3.0 DWPD (Daily Full Disk Write Count during 5-year Warranty)
Total 42.0 PBW (lifetime write volume)
Performance sequential reading: up to 3500 MB/s
Sequential writing: up to 2100 MB/s
Random read: 750000 IOPS (4K)
Random Write: 170000 IOPS (4K)
Power consumption activity power consumption 16W
Idle power consumption 5W
Reliability index MTBF: 2.5 million hours
UBER：＜1e
Key feature - Hybrid workload optimization: Balanced read and write performance
-Enterprise level durability: 3.0 DWPD durability rating
-Advanced Data Protection: Complete Power Failure Protection
-NetApp Deep Integration: Optimized for ONTAP
Technical Features
Performance architecture
Dual port NVMe design, supporting high availability configurations
Intelligent read-write cache management
Adaptive Flash Memory Management Algorithm
reliability characteristics
Full path data protection
End to end data integrity verification
Hot swappable support, online replacement
management function
Support NVMe MI management interface
Real time performance monitoring
Predictive Failure Analysis
system compatibility
Supports NetApp systems:
AFF A-series Full Flash Array (A250/A400/A800)
FAS series hybrid storage array
EF series full flash array
Requirement for ONTAP version:
ONTAP 9.7 and above versions
Recommend using ONTAP 9.10.1+
Management tools:
NetApp System Manager
Active IQ Unified Manager
ONTAPI Command Line Interface
Applicable scenarios
Key applications for enterprises
database
SAP HANA environment
Microsoft SQL Server
virtualization platform
VMware vSphere
Microsoft Hyper-V
OpenStack environment
High Performance Computing
Financial trading system
Real time data analysis
Artificial Intelligence/Machine Learning
